Passante a parete 09452151100 HARTING Contenuto: 1 pz. Passaparete

09 45 215 1100 09452151100
HARTING
Properties overview
Connectors
Contacts: 8
Size: Han
3 A
Material: Zinc alloy
Powder coating
Degree of protection: IP65, IP67
Product Details
Identification
Category
Connectors
Series
RJ45
Element
Wall pass
Specifications
Right
Version
Cut it
Han ® 3 A
Screen
Total shielding, 360 ° shielded contacts
Number of poles
8
Screws
Screwable on the lids
Technical details
Technical features
Cat. 5 Class D up to 100 MHz
Data rate
10 Mbit / s
100 Mbit / s
1 Gbit / s
2.5 Gbit / s
Maximum temperature
-40 ... +70 ° C
Switching on / off cycles
≥ 500
Degree of protection according to IEC 60529
IP65
IP67
Properties of the material
Material (cases)
Zinc alloy
Surface finish (housings)
Powder coating
Color (cases)
Grey
RoHS
Compliant with exemption
RoHS exemptions
6 a) / 6 a) -I: Lead as an alloying element in steel intended for machining and galvanized steel containing up to 0.35% lead by weight / Lead as an alloying element in steel intended for machining mechanics containing up to 0.35% lead by weight and in batch hot dip galvanized steel components and containing up to 0.2% lead by weight
ELV status
Compliant with exemption
China RoHS
50
REACH ANNEX XVII substances
Not included
REACH ANNEX XIV Substances
Not included
REACH SVHC substances
Yup
REACH SVHC substances
Lead
California Proposition 65 substances
Yup
California Proposition 65 substances
Antimony trioxide
Lead
Nickel
Naphthalene
Fire protection on railway vehicles
EN 45545-2 (2020-08)
Set of requirements with risk levels
R22 (HL 1-3)
R23 (HL 1-3)
Specifications and approvals
Approvals
DNV GL
UL / CSA
UL 1977 ECBT2.E102079
CSA-C22.2 No. 182.3 ECBT8.E102079
PROFINET
yes
Commercial data
Packaging dimensions
1
Net weight
50 g
Country of origin
Romania
European customs code
85366990
eCl @ ss
27440101 Rectangular connectors (set)
