Siemens 3SE50000AD04 3SE5000-0AD04 Testa azionamento con elemento LED Stantuffo Nero 1 pz. Pezzo
EAN:
Codice produttore
Articolo n°:
Scheda tecnica (PDF)
Quantità (Pezzo(i))
Risparmio
Prezzo dell'imballaggio (IVA escl.)
1
-
38,52 €
3
3% = 1,26 €
37,26 €
5
5% = 1,76 €
36,76 €
10
5% = 2,09 €
36,43 €
25
6% = 2,46 €
36,06 €
I prezzi a scala possono variare a seconda del venditore
Risparmio 0,00 €
Numero
Totale (38,52 € / Pezzo)
38,52 €
IVA escl.
Solo 5 Pezzo(i) disponibili
Avete già l'offerta migliore per la vostra quantità.
La selezione ottimale per la quantità inserita viene calcolata automaticamente, compresi il prezzo (escl. spedizione) e i tempi di consegna.
Dati tecnici
- Materiale dell'alloggiamento in plastica dell'interruttore testa:
- Tipo di imballaggio
Pezzo
- Tipo prodotto
Testa azionamento
- Caratteristiche
con elemento LED
- Tipo di illuminazione
Senza
- Tipo lampadina
LED (monocolore)
- Azionamento
Stantuffo
- Colore
Nero
- Colore alloggiamento
Nero
- Serigrafia
Senza
- Collegamento
spina M12
- Durata meccanica
1500 0000
- Modello
Rullo in acciaio inox
- Min. temperatura
-25 °C
- Temperatura max.
+85 °C
- Diametro
10 mm
- Adatto per
Interruttore di posizione 3SE51/52
- Contenuto
1 pz.
- Dim.
(Ø) 10 mm
- Compatibile RoHS
Sì
- Tipo
3SE5000-0AD04
- Tipo
3SE5000-0AD04
Other
None
None
None
Roller cam
None
Roller cam straight
- UKCA
Sì
Documenti & Download
Scheda tecnica
Scheda tecnica 703004 Siemens 3SE50000AD04 3SE5000-0AD04 Testa azionamento con elemento LED Stantuffo Nero 1 pz. Pezzo
Istruzioni d'uso e di sicurezza
Istruzioni d'uso e di sicurezza 703004 Siemens 3SE50000AD04 3SE5000-0AD04 Testa azionamento con elemento LED Stantuffo Nero 1 pz. Pezzo
Descrizione
Actuator head for position switch 3SE51/52 Roller plunger, Form C, with Stainless steel roller 10 mm according to EN 50047 actuator head for position switch SIRIUS 3SE5 for position sensing of machine parts and position monitoring of protection equipment.
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
Testo tradotto automaticamente
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
