Highlights & Dettagli

The new v3 version of the Strato Pi CM Duo brings in several innovations, including the support for the new Raspberry Pi Compute Module 4S (CM4S).
Based on the same CPU of the Raspberry Pi 4 Model B, Compute Module 4S is significantly more powerful than the Compute Module 3+ and the older Compute Module 3.
The highlights of Strato Pi CM DUO v3 are the following:
. compatible with Compute Module 3, 3+, 4S, with embedded eMMC
. redesigned real-time-clock circuit with much-improved timekeeping accuracy and extended backup battery life
. enhanced protection of the RS-485 lines,
Strato Pi CM DUO v3 retains the same watchdog, isolated RS-485 port, and USB ports with independent power control and fault detection of Strato Pi CM Duo and previous Strato Pi CM 2.0.

Dati tecnici

Tipo: Strato Pi CM DUO v3 8GB

Tipo prodotto: Modulo di controllo PLC

Dim.: (L x L x A) 36.3 x 36.3 x 90.5 mm

Modello: Strato Pi CM DUO v3

Tensione d'esercizio: 9 - 28 V/DC

Voltaggio Max.: 28 V/DC

Voltaggio operativo Min.: 9 V/DC

Display: No / No

Orologio in tempo reale: Sì (Hardware)

Memoria flash: 8 GB

Soppressione radiodisturbi: CE, FCC, IC

Peso: 155 g

Codice articolo produttore: SCMD30X41

Protezione corto circuito: SI

Larghezza: 36.3 mm

Altezza: 90.5 mm

Lunghezza: 36.3 mm

Profondità: 62 mm

Max. Temperatura ambiente: 80 °C

Min. Temperatura ambiente: -30 °C

Documenti & Download

Scheda tecnica

Scheda tecnica 863861602 Strato Pi CM Duo v3 4S 8GB

Istruzioni d'uso e di sicurezza

Istruzioni d'uso e di sicurezza 863861602 Strato Pi CM Duo v3 4S 8GB

Descrizione

Compact industrial Raspberry Pi, with dual SD card
Strato Pi CM Duo is an extremely powerful and compact industrial server based on Raspberry Pi Compute Module, suitable for use in industrial and professional applications where reliability and service continuity are key requirements.
It is compliant with the low voltage and EMC CE directives, as well as the harmonised standards for electromagnetic compatibility, electrical safety, emission and the RoHS directive for hazardous substances. It is also compliant with the applicable FCC rules and IC standards.
Mounting:
2 modules DIN rail case
power supply and serial connections on pluggable terminal block
Power supply:
9-28Vdc power supply, with surge and reverse polarity protection, and 1.1A resettable fuse
up to 1.9A max continuous current (3A peaks) to the 5V Raspberry Pi Compute Module power supply input pins (at 24Vdc)
Connectivity:
standard RS-485 interface to the Raspberry Pi serial line, with opto-isolator and electrostatic discharge protection
2 x USB 2.0 type-A ports, with individual power control and fault detection
10/100 Ethernet port
High reliability and security:
switchable dual microSD card architecture
hardware watchdog, fully independent from the Raspberry Pi Compute Module, controlled via GPIO, with dual SD card switch control
real time clock (RTC) with replaceable back-up battery
embedded Microchip ATECC608A secure element chip
integrated boot loader for the Strato Pi micro-controller, allowing in-field firmware upgrades directly from the Raspberry Pi
More:
GPIO-controlled LED
LEDs for power supply and serial line activity
recessed push-button, hidden behind the front-panel, connected to a GPIO pin
